GlassOre

Handcast Glass Bricks

QUOTE| |800.426.0279

With the weight and texture of a traditional masonry brick, GlassOre dramatically changes the appearance of a room when lit from behind or underneath. Ideally suited for artistic accents, GlassOre can be used in interior or exterior applications for a striking look.

“Every child is an artist. The problem is how to remain an artist once he grows up.”

-Pablo Picasso

KEY FEATURES


  • Interior and exterior applications
  • Width and texture of a traditional masonry brick
  • Can be lit from behind or underneath
  • Ideal for artistic accents in borders, walkways, walls, monuments and more

Applications:

  • Borders and Accents
  • Walls
  • Monuments
  • Walkways

Performance Data


Surfaces: Rough (except base, which is smooth) Water Absorption Rate: 0.007~0.012 (wt %)
Top Surface Dimensions: 4" x 7.87" (100 mm x 200 mm) Bending Strength: 18 MPa
Tolerance: +1 mm, -2 mm Compression Strength: 80 MPa
Bottom Surface Dimensions: 4" x 7.87" (100 mm x 200 mm) Abrasion Resistance: 0.002~0.005 g
Tolerance: +1 mm, -2 mm Slip Resistance: DRY: 85~91 BPN
Thickness: 2" (50 mm) WET: 40~42 BPN
Tolerance: +3 mm, -2 mm Other Shape Options: BAR: 2" x 2" x 39.4" (50 mm x 50 mm x 1000 mm)
Density: 146 lb/ft3 (2.34 g/cm3) RECTANGLE: 4" x 2" x 24" (100 mm x 50 mm x 600 mm)

These numerical values are measured, not guaranteed. GlassOre bricks have individual characteristics that may differ in thickness, transparency and color tone. Actual color may differ from this representation. Please request a sample brick to confirm.
